PICO TECHNOLOGY  PICOSCOPE 2205 MSO  USB Oscilloscope, PicoScope 2000 Series, 2 Analogue, 16 Digital, 25 MHz, 200 MSPS, 48 kpts, 14 ns

Technical Data Sheet (2.01MB) EN See all Technical Docs

Image is for illustrative purposes only. Please refer to product description.

PICO TECHNOLOGY PICOSCOPE 2205 MSO
PICO TECHNOLOGY PICOSCOPE 2205 MSO
PICO TECHNOLOGY PICOSCOPE 2205 MSO
360°

Product Overview

With the PicoScope 2205 mixed signal oscilloscope (MSO) it is possible for you to measure both analogue and digital signals at the same time, using one device, and view the analogue waveforms and digital data on the same screen. While featuring the 2+16 channel format, still remains a full-featured oscilloscope. A function generator and arbitrary waveform generator are built-in and include a sweep function. It also offers mask limit testing, math and reference channels, advanced digital triggering, serial decoding, automatic measurements and colour persistence display.
  • 2 analogue channels
  • 16 digital channels
  • Measure analogue signals up to 25 MHz
  • Measure digital signals up to 100 MHz
  • 200 MS/s mixed–signal sampling
  • Built–in function generator and arbitrary waveform generator
  • USB powered

Product Information

Product Range:
PicoScope 2000 Series
Scope Channels:
2 Analogue, 16 Digital
Bandwidth:
25MHz
Sampling Rate:
200MSPS
Display Memory Depth:
48 kpts
Calculated Rise Time:
14ns
Kit Contents:
USB Cable, Software CD, User Manual
Warranty:
5 Years
Plug Type:
USB
Input Impedance:
1 Mohm
Scope Type:
PC Based
SVHC:
To Be Advised

Find similar products  grouped by common attribute

Applications

  • Maintenance & Repair;
  • Test & Measurement

Contents

Software and reference CD, Quick start guide and USB cable.
