JJS-15
Fuse, Industrial / Power, Limitron JJS Series, 15 A, 600 VAC, 14.3mm x 38.1mm, 0.56" x 1.5"
Image is for illustrative purposes only. Please refer to product description.
ManufacturerEATON BUSSMANN
Manufacturer Part NoJJS-15
Newark Part No.94F2088
Product RangeLimitron JJS Series
Technical Datasheet
Available to Order
Manufacturer Standard Lead Time: 5 week(s)
| Quantity | Price |
|---|---|
| 10+ | $91.870 |
| 25+ | $84.660 |
| 50+ | $79.360 |
| 100+ | $75.040 |
| 250+ | $68.310 |
Price for:Each
Minimum: 10
Multiple: 10
$918.70
Enter Your Part No/Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
This number will be added to the Order Confirmation, Invoice, Dispatch note, Web confirmation Email and Product Label.
Product Information
ManufacturerEATON BUSSMANN
Manufacturer Part NoJJS-15
Newark Part No.94F2088
Product RangeLimitron JJS Series
Technical Datasheet
Product RangeLimitron JJS Series
Fuse Current15A
Voltage Rating VAC600VAC
Voltage Rating VDC-
Fuse Size Metric14.3mm x 38.1mm
Fuse Size Imperial0.56" x 1.5"
Blow CharacteristicFast Acting
SVHCNo SVHC (10-Jun-2022)
Product Overview
The JJS series Fast Acting Fuse suitable for advanced protection Class-T current-limiting.
- Commonly applied in electric heat circuits, load centre, disconnect switches and meters
- High speed response for semiconductor protection
- Available for printed circuit board applications
- UL component recognized
Applications
Safety, Industrial
Technical Specifications
Product Range
Limitron JJS Series
Voltage Rating VAC
600VAC
Fuse Size Metric
14.3mm x 38.1mm
Blow Characteristic
Fast Acting
Fuse Current
15A
Voltage Rating VDC
-
Fuse Size Imperial
0.56" x 1.5"
SVHC
No SVHC (10-Jun-2022)
Technical Docs (2)
Alternatives for JJS-15
1 Product Found
Legislation and Environmental
US ECCN:EAR99
EU ECCN:Unknown
RoHS Compliant:No
RoHS Phthalates Compliant:No
SVHC:No SVHC (10-Jun-2022)
