Product Information
ManufacturerFINDER
Manufacturer Part No41.52.9.110.0010
Newark Part No.08X7125
Product Range41 Series
Technical Datasheet
Contact ConfigurationDPDT
Coil Voltage110VDC
Contact Current8A
Product Range41 Series
Relay MountingThrough Hole
Coil Type-
Contact Voltage VAC250VAC
Relay TypePower - General Purpose
Relay TerminalsSolder
Contact Voltage VDC-
Contact MaterialSilver Nickel
Coil Resistance24.2kohm
SVHCNo SVHC (21-Jan-2025)
Product Overview
The 41.52.9.110.0010 is a Low profile PCB Relay with DC coil. This 41.52 series relay has 2CO (DPDT) AgNi cadmium-free contact with 5mm contact pin patch and 8mm, 6kV (1.2/50μs) isolation, coil-contacts.
- RT II Environmental protection rating
- -40 to 85°C Operating temperature range
Applications
Industrial
Technical Specifications
Contact Configuration
DPDT
Contact Current
8A
Relay Mounting
Through Hole
Contact Voltage VAC
250VAC
Relay Terminals
Solder
Contact Material
Silver Nickel
SVHC
No SVHC (21-Jan-2025)
Coil Voltage
110VDC
Product Range
41 Series
Coil Type
-
Relay Type
Power - General Purpose
Contact Voltage VDC
-
Coil Resistance
24.2kohm
