DEMAM15PF225
D Sub Connector, HD15, 15 Contacts, Plug, Crimp, DE, DEMAM Series, Stainless Steel Body
Image is for illustrative purposes only. Please refer to product description.
ManufacturerITT CANNON
Manufacturer Part NoDEMAM15PF225
Newark Part No.72R7007
Product RangeDEMAM Series
Technical Datasheet
57 In Stock
Delivery in 2-3 Business days(Supplier Direct Ship)
Order before 9pm EST standard shipping
| Quantity | Price |
|---|---|
| 1+ | $116.990 |
| 5+ | $114.490 |
| 10+ | $111.290 |
| 25+ | $109.550 |
| 50+ | $108.250 |
| 100+ | $107.500 |
Price for:Each
Minimum: 1
Multiple: 1
$116.99
Enter Your Part No/Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
This number will be added to the Order Confirmation, Invoice, Dispatch note, Web confirmation Email and Product Label.
Product Information
ManufacturerITT CANNON
Manufacturer Part NoDEMAM15PF225
Newark Part No.72R7007
Product RangeDEMAM Series
Technical Datasheet
D Sub Connector TypeHigh Density
Product RangeDEMAM Series
No. of Contacts15Contacts
D Sub Shell SizeDE
Contact Termination TypeCrimp
Connector MountingCable Mount
Contact MaterialCopper Alloy
Contact PlatingGold Plated Contacts
Connector Body MaterialStainless Steel Body
SVHCTo Be Advised
Product Overview
The DEMAM15PF225 is a 15-way D-sub Connector with gold over nickel plated copper alloy contacts and passivated stainless steel shell. This D*M series high reliable D-Sub plug features thermoplastic, type PCT UL94V-0 insulator and support crimp contact termination. It accepts 20 to 28AWG standard wire.
- 7.5A Maximum rated current
- 10mΩ Maximum contact resistance
- 1000VAC at sea level Dielectric withstanding voltage
- -55/+150°C Operating temperature range
Applications
Computers & Computer Peripherals
Technical Specifications
D Sub Connector Type
High Density
Product Range
DEMAM Series
D Sub Shell Size
DE
Connector Mounting
Cable Mount
Contact Plating
Gold Plated Contacts
SVHC
To Be Advised
Gender
Plug
No. of Contacts
15Contacts
Contact Termination Type
Crimp
Contact Material
Copper Alloy
Connector Body Material
Stainless Steel Body
