D8M-R1
Pressure Sensor, Solid State, -20 to 70°C, Gauge, 0 Pa, 196.13 Pa, 4.2 VDC, 5.5 VDC, Module
Image is for illustrative purposes only. Please refer to product description.
ManufacturerOMRON INDUSTRIAL AUTOMATION
Manufacturer Part NoD8M-R1
Newark Part No.60K7820
Technical Datasheet
Available to Order by Phone
Delivery estimated post order confirmations.You will be charged on despatch.
Product Information
ManufacturerOMRON INDUSTRIAL AUTOMATION
Manufacturer Part NoD8M-R1
Newark Part No.60K7820
Technical Datasheet
Pressure TypeGauge
Operating Pressure Min0Pa
Operating Pressure Max196.13Pa
Supply Voltage Min4.2VDC
Supply Voltage Max5.5VDC
Sensor Case / PackageModule
No. of Pins3Pins
Sensor Output TypeAnalog
Accuracy-
Pressure Port TypeSingle Radial Barbless
Sensor MountingPanel Mount
Output Interface80-300kHz
Media TypeAir, Gas
Operating Temperature Min-20°C
Operating Temperature Max70°C
Product Range-
Qualification-
SVHCNo SVHC (27-Jun-2018)
Technical Specifications
Pressure Type
Gauge
Operating Pressure Max
196.13Pa
Supply Voltage Max
5.5VDC
No. of Pins
3Pins
Accuracy
-
Sensor Mounting
Panel Mount
Media Type
Air, Gas
Operating Temperature Max
70°C
Qualification
-
Operating Pressure Min
0Pa
Supply Voltage Min
4.2VDC
Sensor Case / Package
Module
Sensor Output Type
Analog
Pressure Port Type
Single Radial Barbless
Output Interface
80-300kHz
Operating Temperature Min
-20°C
Product Range
-
SVHC
No SVHC (27-Jun-2018)
Technical Docs (2)
Legislation and Environmental
US ECCN:EAR99
EU ECCN:Unknown
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:To be advised
SVHC:No SVHC (27-Jun-2018)
