92S7D22D-12
Power Relay, DPST-NO, 12 VDC, 30 A, W92 Series, DIN Rail, Panel
Image is for illustrative purposes only. Please refer to product description.
ManufacturerSCHNEIDER ELECTRIC/LEGACY RELAY
Manufacturer Part No92S7D22D-12
Newark Part No.45P2957
Product RangeW92 Series
Technical Datasheet
506 In Stock
120 more incoming. You can reserve stock now
Same day shipping
Order before 9pm EST standard shipping
Product Information
ManufacturerSCHNEIDER ELECTRIC/LEGACY RELAY
Manufacturer Part No92S7D22D-12
Newark Part No.45P2957
Product RangeW92 Series
Technical Datasheet
Contact ConfigurationDPST-NO
Coil Voltage12VDC
Contact Current30A
Product RangeW92 Series
Relay MountingDIN Rail, Panel
Coil Type-
Contact Voltage VAC250V
Relay TypePower - General Purpose
Relay TerminalsQuick Connect
Contact Voltage VDC28V
Contact MaterialSilver Alloy
Coil Resistance86ohm
SVHCTo Be Advised
Product Overview
The 92S7D22D-12 is a general-purpose Power Relay with DPST-NO silver alloy contact. This W92-series DIN rail mount AC operated power relay features as class-F insulation for maximum coil temperature of 155°C, meets UL, CE, CSA certification.
- Sealed dust cover
- 100000 operations Electrical life
- 5000000 operations Mechanical life at no load
- 15ms Operate time
- -40 to 55°C Ambient operating temperature range
Applications
Industrial
Technical Specifications
Contact Configuration
DPST-NO
Contact Current
30A
Relay Mounting
DIN Rail, Panel
Contact Voltage VAC
250V
Relay Terminals
Quick Connect
Contact Material
Silver Alloy
SVHC
To Be Advised
Coil Voltage
12VDC
Product Range
W92 Series
Coil Type
-
Relay Type
Power - General Purpose
Contact Voltage VDC
28V
Coil Resistance
86ohm
Associated Products
1 Product Found
Legislation and Environmental
US ECCN:EAR99
EU ECCN:Unknown
RoHS Compliant:Y-Ex
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:To Be Advised
