For projects that require a higher level of protection, Newark offers heat shrink boots that deliver excellent strain relief and environmental sealing for connectors and wiring harnesses.

Heat shrink boots are protective coverings that seal and reinforce cable connections, offering added durability and protection from environmental factors. They are designed to insulate and shield from moisture, abrasion and chemicals, while also improving the appearance and durability of cable assemblies.

Newark's heat shrink boots are the perfect choice for rugged and high-performance applications, available in multiple sizes and configurations. Commonly used in aerospace, automotive and defence industries, heat shrink boots provide environmental sealing and strain relief for wiring harnesses.

Manufacturer Part No	Order Code	Manufacturer / Description	Price for	Price	Boot Configuration	For Use With	I.D. Supplied - Imperial	I.D. Supplied - Metric	Shrink Tubing / Boot Colour	Length - Imperial	Total Length - Imperial	Total Length - Metric	Length - Metric	I.D. Recovered Max - Imperial	I.D. Recovered Max - Metric	Shrink Tubing / Boot Material	Shrink Ratio	Product Range

HDBB-205-1-250	81H5423 Data Sheet RoHS	3M Heat Shrink Boot Molded Heavy Duty 1 to 2 Transition 0.8 " 20.32 mm Black 2.7 " 68.58 mm	Each	1+$56.670 5+$46.660 10+$42.910 25+$39.480 50+$35.330 More Pricing...	1 to 2 Transition	-	0.8"	20.32mm	Black	-	2.7"	68.58mm	-	0.37"	9.4mm	PO (Polyolefin)	-	-
382A012-25/225-0	30M0313 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Molded Adhesive Lined Y Transition 0.52 " 13.2 mm Black 1.64 " 41.7 mm	Each	1+$38.640 5+$37.960 10+$36.360 25+$36.180 50+$35.990 More Pricing...	Y Transition	-	0.52"	13.2mm	Black	-	1.64"	41.7mm	-	0.13"	3.3mm	Elastomer	-	-
381A301-71/42-0	36K3055 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Molded Adhesive Lined Y Transition 0.78 " 19.8 mm Black 1.6 " 40.64 mm	Each	1+$70.350 5+$65.610 10+$60.850 25+$58.410 50+$56.750 More Pricing...	Y Transition	-	0.78"	19.8mm	Black	-	1.6"	40.64mm	-	0.26"	6.6mm	PO (Polyolefin)	-	-
202K121-25-0	35K5554 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Molded Straight Lipped 0.95 " 24 mm Black 1.5 " 38 mm	Each	1+$23.620 5+$22.280 10+$20.950 25+$19.310 50+$18.600 More Pricing...	Straight Lipped	-	0.95"	24mm	Black	-	1.5"	38mm	-	0.22"	5.6mm	Elastomer	2.3:1	202K Series
101A011-3-0	43K5080 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot End Cap 0.2 " 5.1 mm Black 0.9 " 22.9 mm	Each	1+$6.210 10+$4.920 25+$4.840 50+$4.750 100+$4.670 More Pricing...	End Cap	-	0.2"	5.1mm	Black	-	0.9"	22.9mm	-	0.08"	2mm	PO (Polyolefin)	-	-
381A301-51/164-0	39K3973 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Y Transition 0.78 " 19.8 mm Black	Each	1+$97.790 5+$88.040 10+$78.280 25+$76.060 50+$72.520	Y Transition	-	0.78"	19.8mm	Black	-	-	-	-	0.26"	6.6mm	Elastomer	-	-
202K132-25-0	21K6225 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Molded Straight Lipped 1.18 " 30 mm Black 2.17 " 55 mm	Each	1+$21.390 5+$20.380 10+$19.520 25+$19.470 50+$19.290 More Pricing...	Straight Lipped	-	1.18"	30mm	Black	-	2.17"	55mm	-	0.23"	5.9mm	Elastomer	2.3:1	202K Series
462A011-15-0	45H3284 Data Sheet RoHS	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Molded 1 to 3 Transition 0.52 " 13.2 mm Black 1.82 " 46.2 mm	Each	1+$105.310 5+$94.850 10+$89.770 25+$87.460 50+$83.220	1 to 3 Transition	-	0.52"	13.2mm	Black	-	1.82"	46.2mm	-	0.14"	3.6mm	PO (Polyolefin)	2:1	-
PD-CAP-1/8-0	21K5472 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot End Cap 0.125 " 3.18 mm Black 1 " 25.4 mm	Each	1+$0.254 25+$0.189 50+$0.177 100+$0.163 500+$0.150 More Pricing...	End Cap	-	0.125"	3.18mm	Black	-	1"	25.4mm	-	0.023"	0.58mm	PO (Polyolefin)	3:1	PD Series
SSC-1/239	18J1285 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - AMP Heat Shrink Boot Molded Adhesive Lined End Cap 0.394 " 10 mm Black 1.5 " 38 mm	Each	1+$26.590 5+$26.260 10+$25.920 25+$25.510 50+$19.590 More Pricing...	End Cap	-	0.394"	10mm	Black	-	1.5"	38mm	-	0.157"	4mm	PO (Polyolefin)	3:1	-
382A012-4/86-0	42K5368 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Molded Adhesive Lined Y Transition 0.52 " 13.21 mm Black 1.64 " 41.656 mm	Each	1+$50.110 5+$47.010 10+$43.900 25+$41.950 50+$39.950 More Pricing...	Y Transition	-	0.52"	13.21mm	Black	-	1.64"	41.656mm	-	0.13"	3.3mm	PO (Polyolefin)	-	-
TC-CAPS-4001-9	24K0527 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Semirigid Flame Retardant End Cap 0.063 " 1.6 mm White 0.75 " 19.1 mm	Each	1+$0.934 10+$0.721 25+$0.684 50+$0.645 100+$0.607 More Pricing...	End Cap	-	0.063"	1.6mm	White	-	0.75"	19.1mm	-	0.03"	0.8mm	PO (Polyolefin)	2.5:1	TC Caps Series
382A012-25-0	77J6861 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Molded Y Transition 0.52 " 13.2 mm Black 0.94 " 23.9 mm	Each	1+$37.770 5+$36.700 10+$35.630 25+$35.040 50+$34.510 More Pricing...	Y Transition	-	0.52"	13.2mm	Black	-	0.94"	23.9mm	-	0.24"	6.1mm	Elastomer	2:1	-
D-150-C-14	05W4815 Data Sheet RoHS	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Repair Sleeve C-Wrap Side Straight 0.189 " 4.8 mm Yellow 0.75 " 19.05 mm	Each	1+$23.710 5+$23.130 10+$22.550 25+$21.530 50+$19.420 More Pricing...	Straight	-	0.189"	4.8mm	Yellow	-	0.75"	19.05mm	-	-	-	Fluoropolymer	-	-
202D121-3/42-0	63K2492 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Molded Adhesive Lined Straight Lipped 0.92 " 23.3 mm Black 1.5 " 38.1 mm	Each	1+$33.890 5+$31.790 10+$29.690 25+$28.400 50+$27.480 More Pricing...	Straight Lipped	-	0.92"	23.3mm	Black	-	1.5"	38.1mm	-	0.22"	5.6mm	PO (Polyolefin)	-	-
ES-CAP-NO.1-C1-0-30MM	43M2743 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot End Cap 0.225 " 5.72 mm Black 1.18 " 30 mm	Each	1+$0.317 25+$0.265 50+$0.250 100+$0.229 500+$0.211 More Pricing...	End Cap	-	0.225"	5.72mm	Black	-	1.18"	30mm	-	0.05"	1.27mm	PO (Polyolefin)	4:1	ES Series
202K132-25/225-0	72J7408 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Molded Adhesive Lined Straight Lipped 1.18 " 30 mm Black 2.17 " 55 mm	Each	1+$27.080 5+$25.480 10+$23.880 25+$22.640 50+$22.090 More Pricing...	Straight Lipped	-	1.18"	30mm	Black	-	2.17"	55mm	-	0.56"	5.9mm	Elastomer	-	202K Series
770-003A104	97AH7087 Data Sheet RoHS	GLENAIR Heat Shrink Boot Right Angle Lipped 1.181 " 30 mm Black	Each	1+$165.420 2+$143.450 4+$138.560 7+$120.610 10+$103.120 More Pricing...	Right Angle Lipped	-	1.181"	30mm	Black	-	-	-	-	0.532"	13.5mm	Elastomer	-	77 Series
222A111-25-0	25M1815 Data Sheet RoHS	TE CONNECTIVITY - RAYCHEM HEATSHRINK BOOT RIGHT ANGLE	Each	1+$28.480 5+$27.620 10+$26.740 25+$24.260 50+$23.670 More Pricing...	Right Angle	-	0.7"	17.8mm	Black	-	0.68"	17.3mm	-	0.15"	3.8mm	Elastomer	2.3:1	-
222K121-25L-0	30AH0392 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Right Angle Lipped 0.94 " 24 mm Black 0.98 " 25 mm	Each	1+$27.230 5+$26.150 10+$25.050 25+$23.030 50+$22.310 More Pricing...	Right Angle Lipped	-	0.94"	24mm	Black	-	0.98"	25mm	-	0.22"	5.6mm	Elastomer	-	-
222K163-25L-0	30AH0395 Data Sheet RoHS	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Right Angle Lipped 1.69 " 43 mm Black 2.17 " 55 mm	Each	1+$50.120 5+$46.630 10+$43.150 25+$41.280 50+$39.950 More Pricing...	Right Angle Lipped	-	1.69"	43mm	Black	-	2.17"	55mm	-	0.39"	9.9mm	Elastomer	-	-
770-003B103W1	97AH7128 Data Sheet RoHS	GLENAIR Heat Shrink Boot Acute Angle Lipped 0.945 " 24 mm Black	Each	1+$50.100 2+$49.090 4+$48.520 7+$48.510 10+$48.490 More Pricing...	Acute Angle Lipped	-	0.945"	24mm	Black	-	-	-	-	0.413"	10.5mm	Elastomer	-	77 Series
202K132-3-0	39K1553 Data Sheet RoHS	TE CONNECTIVITY - RAYCHEM HEATSHRINK LIPPED STRAIGHT PART	Each	1+$25.490 5+$24.260 10+$23.020 25+$21.800 50+$20.930 More Pricing...	Straight Lipped	-	1.18"	30mm	Black	-	2.17"	55mm	-	0.56"	14.2mm	PO (Polyolefin)	2.1:1	202K Series
202A111-25/86-0	61J4584 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - RAYCHEM Heat Shrink Boot Molded Straight 0.65 " 16.5 mm Black 1 " 25.4 mm	Each	1+$25.970 5+$25.180 10+$24.370 25+$23.490 50+$22.850 More Pricing...	Straight	-	0.65"	16.5mm	Black	-	1"	25.4mm	-	0.15"	3.8mm	Elastomer	-	-
770-003S303	97AH7199 Data Sheet RoHS	GLENAIR Heat Shrink Boot Straight Lipped 0.945 " 24 mm Black 1.496 " 38 mm	Each	1+$140.750 2+$122.040 4+$117.840 7+$102.600 10+$87.720 More Pricing...	Straight Lipped	-	0.945"	24mm	Black	-	1.496"	38mm	-	0.413"	10.5mm	PO (Polyolefin)	-	77 Series
