CPC1909J
MOSFET Relay, SPST-NO (1 Form A), AC / DC, 60 V, 15 A, ISOPLUS-264, Through Hole
Image is for illustrative purposes only. Please refer to product description.
ManufacturerIXYS SEMICONDUCTOR
Manufacturer Part NoCPC1909J
Newark Part No.30K7141
Product RangeOptoMOS Series
Technical Datasheet
222 In Stock
Need more?
Same day shipping
Order before 9pm EST standard shipping
| Quantity | Price |
|---|---|
| 1+ | $14.040 |
| 10+ | $13.100 |
| 25+ | $11.140 |
| 50+ | $10.900 |
| 100+ | $10.650 |
| 250+ | $10.030 |
| 500+ | $9.980 |
Price for:Each
Minimum: 1
Multiple: 1
$14.04
Enter Your Part No/Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
This number will be added to the Order Confirmation, Invoice, Dispatch note, Web confirmation Email and Product Label.
Product Information
ManufacturerIXYS SEMICONDUCTOR
Manufacturer Part NoCPC1909J
Newark Part No.30K7141
Product RangeOptoMOS Series
Technical Datasheet
Contact FormSPST-NO (1 Form A)
Load TypeAC / DC
Relay TerminalsPC Pin
Load Voltage Max60V
Load Current15A
MOSFET Relay Package StyleISOPLUS-264
Relay MountingThrough Hole
Forward Current If10mA
On State Resistance Max0.1ohm
Isolation Voltage2.5kV
I/O Capacitance Typ1pF
Off State Leakage Current Max1µA
Product RangeOptoMOS Series
SVHCNo SVHC (17-Jan-2023)
Technical Specifications
Contact Form
SPST-NO (1 Form A)
Relay Terminals
PC Pin
Load Current
15A
Relay Mounting
Through Hole
On State Resistance Max
0.1ohm
I/O Capacitance Typ
1pF
Product Range
OptoMOS Series
Load Type
AC / DC
Load Voltage Max
60V
MOSFET Relay Package Style
ISOPLUS-264
Forward Current If
10mA
Isolation Voltage
2.5kV
Off State Leakage Current Max
1µA
SVHC
No SVHC (17-Jan-2023)
Technical Docs (2)
Legislation and Environmental
US ECCN:EAR99
EU ECCN:Unknown
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:No SVHC (17-Jan-2023)
