DF-A0047

Antenna, LPDA, 20Mhz-8.5Ghz, 50 Ohm, Combined Loop / LPDA, Gain 6Db, 50 Ohm, Horizontal / Vertical

TEKTRONIX DF-A0047

Image is for illustrative purposes only. Please refer to product description.

Manufacturer:
TEKTRONIX TEKTRONIX
Manufacturer Part No:
DF-A0047
Newark Part No.:
78Y7761
Technical Datasheet:
DF-A0047   Datasheet
See all Technical Docs

Product Information

Want to see similar products? Simply select your required attributes below and hit the button ×


:
Combined Loop / LPDA

:
20MHz

:
8.5GHz

:
-

:
6dB

:
3.5

:
-

:
50ohm

:
Horizontal / Vertical

:
-

Find similar products Choose and modify the attributes above to find similar products.

Technical Docs (2)

Product Overview

IP56 rated Alaris handheld direction finding antenna for use in interference hunting applications with Tektronix USB spectrum analysers and SignalVu-PC Map application software.
  • Combined loop/log-periodic dipole array antenna
  • 20MHz to 8500MHz frequency
  • Internal preamp can be used or bypassed
  • Rotating trigger-switch to control operating bands, preamp on/off and transmit bearing
  • Horizontal or vertical polarization

Applications

Wireless

Best Seller

0 In stock

Non-Cancelable / Non Returnable

$11,634.30

Pricing is unavailable. Please contact customer services.

Price for:
Each
Multiple: 1 Minimum: 1
Quantity Price Your Price


1+ $11,634.30
