Available to Order
Manufacturer Standard Lead Time: 14 week(s)
Notify me when back in stock
| Quantity | Price |
|---|---|
| 1+ | $10.880 |
| 5+ | $10.580 |
| 10+ | $10.270 |
| 25+ | $9.940 |
| 50+ | $9.630 |
| 100+ | $9.130 |
| 250+ | $8.790 |
Price for:Each
Minimum: 1
Multiple: 1
$10.88
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
| Manufacturer | GRAYHILL |
|---|---|
| Manufacturer Part No | 30-3Copy |
| Manufacturer Standard Lead Time | 14 weeks |
| Newark Part No. | 57F2616 |
| Product Range | 30 Series |
| Technical Datasheet | |
| Pushbutton Switch Type | Standard |
| Panel Cutout Diameter | 6.8mm |
| Product Range | 30 Series |
| Contact Voltage AC Nom | 220V |
| Contact Configuration | SPST-NO |
| Switch Operation | Off-(On) |
| Contact Current Max | 1A |
| Pushbutton Actuator Style | Round Plunger |
| Actuator / Cap Colour | Black |
| Contact Current AC Max | 1A |
| Contact Voltage VAC | 115V |
| Contact Current DC Max | - |
| Contact Voltage VDC | - |
| IP Rating | - |
| Switch Mounting | Panel Mount |
| Switch Terminals | Solder Lug |
| Illumination Color | Non Illuminated |
| Panel Cutout (H x W) | - |
| SVHC | No SVHC (25-Jun-2025) |
Product Overview
The 30-3 is a single-pole single-throw normally open butt contact Pushbutton Switch with brass, tin zinc mounting nut and cover bushing, thermoset plastic base, solder lug terminal type, momentary action, red polycarbonate button and tinned music wire spring.
- 25mΩ Contact resistance
- 1000MΩ Minimum insulation resistance
- -40 to +85°C Operating temperature range
Applications
Industrial
Technical Specifications
| Pushbutton Switch Type | Standard |
|---|---|
| Product Range | 30 Series |
| Contact Configuration | SPST-NO |
| Contact Current Max | 1A |
| Actuator / Cap Colour | Black |
| Contact Voltage VAC | 115V |
| Contact Voltage VDC | - |
| Switch Mounting | Panel Mount |
| Illumination Color | Non Illuminated |
| SVHC | No SVHC (25-Jun-2025) |
| Panel Cutout Diameter | 6.8mm |
|---|---|
| Contact Voltage AC Nom | 220V |
| Switch Operation | Off-(On) |
| Pushbutton Actuator Style | Round Plunger |
| Contact Current AC Max | 1A |
| Contact Current DC Max | - |
| IP Rating | - |
| Switch Terminals | Solder Lug |
| Panel Cutout (H x W) | - |
Technical Docs (3)
Alternatives for 30-3
3 Products Found
Associated Products
1 Product Found
Legislation and Environmental
| US ECCN: | EAR99 |
|---|---|
| EU ECCN: | Unknown |
| RoHS Compliant: | Yes RoHS |
| RoHS Phthalates Compliant: | Yes RoHS |
| SVHC: | No SVHC (25-Jun-2025) |
| Download Product Compliance Certificate | Product Compliance Certificate |
| Product traceability |
