NC3MXX-B

The NC3MXX-B is a 3-pole Male XLR Cable Connector with black metal housing and gold contacts. It has polyamide insert, polyurethane boot, black chromium-plated zinc die-cast shell and zinc die-cast locking element. This XX series connector offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief. Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster, boot with polyurethane gland gives high protection to cable bending stresses.

• With improved locking recess without window, more stringent housing increases durability
• Sleek and ergonomic design - Valuable and handy
• Rugged zinc die-cast shell, long-lasting and dependable
• Internal thread on shell is well protected against any damage
• UL94HB Flammability rating
• IP40 Protection rating
• Complies with IEC 61076-2-103 standard
• Solderability complies with IEC 68-2-20 standard
• ≤3mΩ Contact resistance
• <gt/>10GΩ Insulation resistance
• 16A Current rating per contact
• <lt/>50V Voltage rating
• -30 to +80°C Temperature range

Applications

Audio
