PMR-24V320W1AT
AC/DC Enclosed Power Supply (PSU), 21.6V to 26.4V, ITE & Household, 1 Outputs, 321.6 W, 24 V
L'image a des fins d'illustration uniquement. Veuillez lire la description du produit.
FabricantDELTA ELECTRONICS
Réf. FabricantPMR-24V320W1AT
Code Commande49AK0037
Gamme de produitPMR Series
Fiche technique
Disponible sur commande
Délais d’approvisionnement standard du fabricant : 54 semaine(s)
| Quantité | Prix |
|---|---|
| 1+ | 134,830 $ |
| 120+ | 128,410 $ |
| 240+ | 122,280 $ |
Prix pour :Each
Minimum: 24
Multiple: 12
3 235,92 $
Ajouter Référence Interne / Note à la ligne
Ajouté à votre confirmation de commande, à votre facture et à votre note d’expédition pour cette commande uniquement.
Ce numéro sera ajouté à la confirmation de commande, à la facture, au bon d’expédition, au courriel de confirmation Web et à l’étiquette.
Informations produit
FabricantDELTA ELECTRONICS
Réf. FabricantPMR-24V320W1AT
Code Commande49AK0037
Gamme de produitPMR Series
Fiche technique
Power Supply ApplicationsITE & Household
No. of Outputs1Outputs
Output Power Max321.6W
Output Voltage - Output 124V
Output Current - Output 113.4A
Output Voltage - Output 2-
Output Current - Output 2-
Output Voltage - Output 3-
Output Current - Output 3-
Output Voltage - Output 4-
Output Current - Output 4-
Input Voltage VAC90V AC to 264V AC
Power Supply Output TypeAdjustable, Fixed
Product RangePMR Series
SVHCTo Be Advised
Aperçu du produit
PMR-24V320W1AT is a PMH panel mount power supply. It obtains shock and vibration certification IEC 60068-2. The product is designed in a 30mm low profile and comes with a universal AC input voltage ranging from 90VAC to 264VAC. This is made for installation in limited spaces. Its built-in active PFC circuit provides high power factor values and conforms to harmonic current emission standards IEC/EN 61000-3-2, class A and class D. It includes overvoltage, overload, overcurrent, over temperature, short circuit protection. Application includes building automation, household appliance.
- Rated output voltage is 24V, rated output current is 13.4A, output power is 320.4W (max)
- Typical efficiency at 100% load is 91% (230VAC)
- Single phase, terminal block connector type
- No load power consumption < 0.5W
- Low profile design is 30mm height
- Household appliance approvals according to IEC/EN 60335-1, IEC/EN 61558-1 and IEC/EN 61558-2-16
- Built-in active PFC and conforms to harmonic current IEC/EN 61000-3-2, Class A and Class D
- Operating temperature range from -30°C to +70°C (-40°C cold start)
- Dimensions (L x W x D) is 8.46 x 4.53 x 1.18inch
Spécifications techniques
Power Supply Applications
ITE & Household
Output Power Max
321.6W
Output Current - Output 1
13.4A
Output Current - Output 2
-
Output Current - Output 3
-
Output Current - Output 4
-
Power Supply Output Type
Adjustable, Fixed
SVHC
To Be Advised
No. of Outputs
1Outputs
Output Voltage - Output 1
24V
Output Voltage - Output 2
-
Output Voltage - Output 3
-
Output Voltage - Output 4
-
Input Voltage VAC
90V AC to 264V AC
Product Range
PMR Series
Documents techniques (1)
Législation et Questions environnementales
US ECCN:EAR99
EU ECCN:Unknown
Conforme RoHS :Y-Ex
RoHS
Conforme à la norme RoHS Phthalates:Oui
RoHS
SVHC :To Be Advised
