129664
Flow Sensor, FS-150 Series, Straight Flow Path, Low Pressure Drop, 4 gpm, 1/2˝ NPT, 13.8 bar
L'image a des fins d'illustration uniquement. Veuillez lire la description du produit.
Impossible de récupérer les informations sur la disponibilité
Informations produit
FabricantGEMS SENSORS
Réf. Fabricant129664
Code Commande92C8693
Fiche technique
Flow Rate Min-
Flow Rate Max-
Supply Voltage Min-
Supply Voltage Max-
Product Range-
SVHCNo SVHC (21-Jan-2025)
Aperçu du produit
The FS-150 series slim Inline Switches reduce pressure drop to a minimum. They incorporate unique, dual-diameter, internal bore and piston configuration to minimize flow constriction. Liquids are able to smoothly pass around the piston and flow through the switch with little pressure loss to the down stream line.
- 0.5 to 5GPM Liquid flow rate settings
- Fixed setting type
- 1/2" NPT port size
- Polypropylene primary construction material
- 200psig (13.8bar) at 70 to 150°F (21.1°C to 65.5°C) Maximum operating pressure
- ±15% Set point accuracy
- 20% Maximum set point differential
- 20VA SPDT switch
- 1/4" Male quick connect terminals electrical termination
Applications
Sensing & Instrumentation, Industrial
Spécifications techniques
Flow Rate Min
-
Supply Voltage Min
-
Product Range
-
Flow Rate Max
-
Supply Voltage Max
-
SVHC
No SVHC (21-Jan-2025)
Documents techniques (1)
Législation et Questions environnementales
US ECCN:EAR99
EU ECCN:Unknown
Conforme RoHS :Non
Conforme à la norme RoHS Phthalates:À déterminer
SVHC :No SVHC (21-Jan-2025)
