FabricantMURATA POWER SOLUTIONS
Réf. FabricantMYBSP0055AABFT
Code Commande39AH6981
Gamme de produitMYBSP Series
Fiche technique
Disponible sur commande
Délais d’approvisionnement standard du fabricant : 28 semaine(s)
Quantité | Prix |
---|---|
100+ | 34,590 $ |
250+ | 33,420 $ |
Prix pour :Each (Supplied on Cut Tape)
Minimum: 200
Multiple: 200
6 918,00 $
Ajouter Référence Interne / Note à la ligne
Ajouté à votre confirmation de commande, à votre facture et à votre note d’expédition pour cette commande uniquement.
Ce numéro sera ajouté à la confirmation de commande, à la facture, au bon d’expédition, au courriel de confirmation Web et à l’étiquette.
Informations produit
FabricantMURATA POWER SOLUTIONS
Réf. FabricantMYBSP0055AABFT
Code Commande39AH6981
Gamme de produitMYBSP Series
Fiche technique
Power Supply Applications-
DC / DC Converter Type-
Input Ratio2:1
Output Power Max25.5W
No. of Outputs1 Output
Output Voltage - Output 15V
Output Current - Output 15.1A
Output Voltage - Output 2-
Output Current - Output 2-
Output Regulation-
Isolation Voltage2.25kV
Input Voltage DC Nom48V
DC / DC Converter Output TypeFixed
Width35.5mm
Height10.55mm
DC / DC Converter MountingSurface Mount Device
Depth22.4mm
Input Voltage DC Min37V
Input Voltage DC Max57V
Product RangeMYBSP Series
SVHCNo SVHC (07-Nov-2024)
Aperçu du produit
- Isolated DC-DC converter for PoE PD
- Support IEEE802.3at class4
- Support Type2 PSE indicator
- Support adapter ORing
- Surface mount module
- 2250VDC input-output isolation
- Operating temperature range from -40 to +85°C
- 90.5% efficiency (typ)
- Module has self-protection features
- Include input undervoltage lockout and output current limit
Spécifications techniques
Power Supply Applications
-
Input Ratio
2:1
No. of Outputs
1 Output
Output Current - Output 1
5.1A
Output Current - Output 2
-
Isolation Voltage
2.25kV
DC / DC Converter Output Type
Fixed
Height
10.55mm
Depth
22.4mm
Input Voltage DC Max
57V
SVHC
No SVHC (07-Nov-2024)
DC / DC Converter Type
-
Output Power Max
25.5W
Output Voltage - Output 1
5V
Output Voltage - Output 2
-
Output Regulation
-
Input Voltage DC Nom
48V
Width
35.5mm
DC / DC Converter Mounting
Surface Mount Device
Input Voltage DC Min
37V
Product Range
MYBSP Series
